| MODEL |
CQPD301LKA01 |
|
Processor |
AX3292 （Three recording）
|
|
Image Sensor |
Front: GC030 + GC0309 + OV09 |
|
FOV |
120° wide angle |
|
Max Video Res. |
1080P 1920*1080 |
|
Encoding Capability |
1080P 25fps + 720 25fps + VGA 25fps preview |
|
Video Format |
H.264 encoding ，AVI ;
|
|
Effective Pixels |
Single recording 2MP ;
|
|
Photo Format |
JPEG (720P+VGA+VGA) |
|
Record pattern
|
Loop recording without frame loss ;
|
|
Storage |
TF Card (Class 10 or above, with a maximum support of 64GB) ; |
|
Internal Storage |
EMMC |
|
Boot Time |
5S |
|
Working Voltage |
DC5V（Dedicated car charger for power supply） |
|
Working Current |
Double recording :210mA 5.0V; |
|
Static Current |
< 1mA |
|
Battery Type |
Polymer button battery 150MA ; |
|
Wide Voltage Support |
Supports 12V/24V car power supply ; |
|
LCD |
2.0inch |
WIFI: 2.4G
|
|
IO |
TYPE-C *1 |
Micro TF *1 |
|
AV IN *1 |
|
|
OS system |
RTOS |
Weight: 66g |
|
SIZE |
105x45x38mm |
Hosuing: Plastic |
|
Language |
Russian, Japanese, French, ltalian, German,English and others |
Operation Temp: -20~+70 |
